Configure Angular 4

Published about 7 years ago

Install Npm and NodeJS

  • see install_type_script.md

Create these files

// package.json

{
  "name": "freelance-camp-fe",
  "version": "1.0.0",
  "scripts": {
    "start": "concurrently \"npm run tsc:w\" \"npm run lite\" ",
    "lite": "lite-server",
    "tsc": "tsc",
    "tsc:w": "tsc -w"
  },
  "licenses": [
    {
      "type": "MIT",
      "url": "https://github.com/angular/angular.io/blob/master/LICENSE"
    }
  ],
  "dependencies": {
    "@angular/common": "~2.1.1",
    "@angular/compiler": "~2.1.1",
    "@angular/core": "~2.1.1",
    "@angular/forms": "~2.1.1",
    "@angular/http": "~2.1.1",
    "@angular/platform-browser": "~2.1.1",
    "@angular/platform-browser-dynamic": "~2.1.1",
    "@angular/router": "~3.1.1",
    "@angular/upgrade": "~2.1.1",
    "angular-in-memory-web-api": "~0.1.13",
    "core-js": "^2.4.1",
    "reflect-metadata": "^0.1.8",
    "rxjs": "5.0.0-beta.12",
    "systemjs": "0.19.39",
    "zone.js": "^0.6.25"
  },
  "devDependencies": {
    "@types/core-js": "^0.9.34",
    "@types/node": "^6.0.45",
    "concurrently": "^3.0.0",
    "lite-server": "^2.2.2",
    "typescript": "^2.0.3"
  }
}

// tsconfig.json

{
  "compilerOptions": {
    "target": "es5",
    "module": "commonjs",
    "moduleResolution": "node",
    "sourceMap": true,
    "emitDecoratorMetadata": true,
    "experimentalDecorators": true,
    "removeComments": false,
    "noImplicitAny": false
  }
}

// systemjs.config.js

/**
 * System configuration for Angular samples
 * Adjust as necessary for your application needs.
 */
(function (global) {
  System.config({
    paths: {
      // paths serve as alias
      'npm:': 'node_modules/'
    },
    // map tells the System loader where to look for things
    map: {
      // our app is within the app folder
      app: 'app',
      // angular bundles
      '@angular/core': 'npm:@angular/core/bundles/core.umd.js',
      '@angular/common': 'npm:@angular/common/bundles/common.umd.js',
      '@angular/compiler': 'npm:@angular/compiler/bundles/compiler.umd.js',
      '@angular/platform-browser': 'npm:@angular/platform-browser/bundles/platform-browser.umd.js',
      '@angular/platform-browser-dynamic': 'npm:@angular/platform-browser-dynamic/bundles/platform-browser-dynamic.umd.js',
      '@angular/http': 'npm:@angular/http/bundles/http.umd.js',
      '@angular/router': 'npm:@angular/router/bundles/router.umd.js',
      '@angular/forms': 'npm:@angular/forms/bundles/forms.umd.js',
      '@angular/upgrade': 'npm:@angular/upgrade/bundles/upgrade.umd.js',
      // other libraries
      'rxjs':                      'npm:rxjs',
      'angular-in-memory-web-api': 'npm:angular-in-memory-web-api/bundles/in-memory-web-api.umd.js'
    },
    // packages tells the System loader how to load when no filename and/or no extension
    packages: {
      app: {
        main: './main.js',
        defaultExtension: 'js'
      },
      rxjs: {
        defaultExtension: 'js'
      }
    }
  });
})(this);

Then run this command in the directory you are running your project in

sudo npm install

Then create a plaintext mkdir app followed by:

touch app.module.ts
touch main.ts
touch homepage.component.ts

To start the server, type npm start

-------------------------------

// package.json (after bootstrap, this is for angular 4)

{
  "name": "freelance-camp-fe",
  "version": "1.0.0",
  "scripts": {
    "start": "tsc && concurrently \"npm run tsc:w\" \"npm run lite\" ",
    "lite": "lite-server",
    "tsc": "tsc",
    "tsc:w": "tsc -w"
  },
  "licenses": [
    {
      "type": "MIT",
      "url": "https://github.com/angular/angular.io/blob/master/LICENSE"
    }
  ],
  "dependencies": {
    "@angular/common": "^4.3.2",
    "@angular/compiler": "^4.3.2",
    "@angular/core": "^4.3.2",
    "@angular/forms": "^4.3.2",
    "@angular/http": "^4.3.2",
    "@angular/platform-browser": "^4.3.2",
    "@angular/platform-browser-dynamic": "^4.3.2",
    "@angular/router": "^4.3.2",
    "@ng-bootstrap/ng-bootstrap": "^1.0.0-alpha.29",
    "core-js": "^2.4.1",
    "latest": "^0.2.0",
    "recompile": "^1.0.1",
    "reflect-metadata": "^0.1.8",
    "rxjs": "^5.4.2",
    "systemjs": "0.19.39",
    "to": "^0.2.9",
    "zone.js": "^0.8.4"
  },
  "devDependencies": {
    "@types/core-js": "^0.9.34",
    "@types/node": "^6.0.45",
    "concurrently": "^3.0.0",
    "lite-server": "^2.2.2",
    "typescript": "^2.4.2"
  }
}


// tsconfig.json
{
    "compilerOptions": {
        "emitDecoratorMetadata": true,
        "experimentalDecorators": true,
        "lib": [ "es2015", "dom" ],
        "module": "commonjs",
        "moduleResolution": "node",
        "noImplicitAny": true,
        "sourceMap": true,
        "suppressImplicitAnyIndexErrors": true,
        "target": "es5"

    },
    "exclude": [
        "node_modules/*"
    ]
}

-------------------------------

Creating the main app files

We need to create an AppRoutingModule, AppComponent, AppComponent.html, AppModule, and Main.ts files for the app to be able to bootstrap.

Sample file are found below:

// app-routing-module.ts

import { NgModule } from '@angular/core';
import { RouterModule, Routes } from '@angular/router';

import { HomepageComponent } from './homepage/homepage.component';
import { DocumentsComponent } from './documents/documents.component';
import { ProposalListComponent } from './proposal/proposal-list.component';
import { ProposalNewComponent } from './proposal/proposal-new.component';

const routes : Routes = [
  { path: '', redirectTo: '/home', pathMatch: 'full' },
  { path: 'home', component: HomepageComponent },
  { path: 'documents', component: DocumentsComponent },
  { path: 'proposals', component: ProposalListComponent },
  { path: 'proposals/new', component: ProposalNewComponent },
]

@NgModule({
  imports: [ RouterModule.forRoot(routes) ],
  exports: [ RouterModule ]
})
export class AppRoutingModule {}

// app.module.ts
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { FormsModule } from '@angular/forms';

import { AppRoutingModule } from './app-routing.module';

import { HomepageComponent } from './homepage/homepage.component';
import { AppComponent } from './app.component';
import { DocumentsComponent } from './documents/documents.component';
import { ProposalListComponent } from './proposal/proposal-list.component';
import { ProposalNewComponent } from './proposal/proposal-new.component';

@NgModule({
  imports: [
    BrowserModule,
    AppRoutingModule,
    FormsModule
  ],
  declarations: [
    AppComponent,
    HomepageComponent,
    DocumentsComponent,
    ProposalListComponent,
    ProposalNewComponent
  ],
  bootstrap: [
    AppComponent
  ]
})
export class AppModule {}

// app.component.ts
import  { Component } from '@angular/core';

@Component({
  moduleId: module.id,
  selector: 'app',
  templateUrl: 'app.component.html'
})
export class AppComponent {
  title: 'Freelance Bootcamp Dashboard';
}

<!-- app.component.html -->
<h1>Navigation</h1>

<a routerLink="/home">Home</a>
<a routerLink="/documents">Docs</a>
<a routerLink="/proposals">Proposals</a>
<a routerLink="/proposals/new">New Proposal</a>


<router-outlet></router-outlet>

// main.ts
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { AppModule } from './app.module';

const platform = platformBrowserDynamic();
platform.bootstrapModule(AppModule);
